FDS6670S

FDS6670S, N-channel powertrench sync FET , 30 V, 13 A, 2.5 W, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.20~0.20 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 2145 :	0.20 / Piece

PartNumber:: FDS6670S

Brand:: Fairchild Semiconductor - Fairchild | Pack: SOP | D/C: 03+

Availability:: Supply Ability: 100/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-08

From Other Seller

Part Number:FDS6670S
US $0.20 - 0.20
Quantity:

piece

Product Summary

The FDS6670S is an N-Channel Logic Level MOSFET produced using Fairchild Semiconductors advanced PowerTrench process that has been especially tailored to minimize the on-state resistance and yet maintain superior switching performance. The FDS6670S is well suited for low voltage and battery powered applications where low in-line power loss and fast switching are required.

Parametrics

FDS6670S absolute maximum ratings: (1)VDSS, Drain-Source Voltage: 30 V; (2)VGSS, Gate-Source Voltage: ±20 V; (3)ID, Drain Current, Continuous (Note 1a): 13 A; Pulsed: 50A; (4)PD, Power Dissipation for Single Operation (Note 1a): 2.5 W; (Note 1b): 1.2W; (Note 1c): 1W; (5)TJ,TSTG, Operating and Storage Temperature Range: -55 to 150℃.

Features

FDS6670S features: (1)13 A, 30 V. RDS(ON) = 0.008 W @ VGS = 10 V, RDS(ON) = 0.010W @ VGS = 4.5 V; (2)Fast switching speed; (3)Low gate charge (35 nC tyical); (4)High performance trench technology for extremely low RDS(ON); (5)High power and current handling capability.
