BD9106FVM-TR

BD9106FVM-TR, step-down switching regulator, 7V, 587.4 mW, MSOP8

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.24~0.24 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 2000 :	0.24 / Piece

PartNumber:: BD9106FVM-TR

Brand:: Rohm Semiconductor - Rohm | Pack: | D/C: 08+

Availability:: Supply Ability: 2000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-09-10

From Other Seller

Part Number:BD9106FVM-TR
US $0.24 - 0.24
Quantity:

piece

Product Summary

The bd9106fvm-tr is a high efficiency step-down switching regulator. The bd9106fvm-tr is a power supply designed to produce a low voltage including 1.24 volts from 5 volts power supply line. Offers high efficiency with our original pulse skip control technology and synchronous rectifier. Employs a current mode control system to provide faster transient response to sudden change in load. Applications are power supply for HDD, power supply for portable electronic devices like PDA, and power supply for LSI including CPU and ASIC.

Parametrics

bd9106fvm-tr absolute maximum ratings: (1)VCC voltage VCC: -0.3～+7V; (2)PVCC voltage PVCC: -0.3～+7V; (3)EN voltage EN: -0.3～+7 V; (4)SW,ITH voltage SW,ITH: -0.3～+7 V; (5)Power dissipation 1 Pd1: 387.5 mW; (6)Power dissipation 2 Pd2: 587.4 mW; (7)Operating temperature range Topr: -25～+85 ℃; (8)Storage temperature range Tstg: -55～+150 ℃.

Features

bd9106fvm-tr features: (1)Offers fast transient response with current mode PWM control system.; (2)Offers highly efficiency for all load range with synchronous rectifier (Nch/Pch FET)and SLLMTM (Simple Light Load Mode); (3)Incorporates soft-start function.; (4)Incorporates thermal protection and ULVO functions.; (5)Incorporates short-current protection circuit with time delay function.; (6)Incorporates shutdown function; (7)Employs small surface mount package MSOP8.
