Product Summary

The ap1084t33l-u is a low dropout positive adjustable or fixed-mode regulator with 5.0A output current capability. The product is specifically designed to provide well-regulated supply for low voltage IC applications such as high-speed bus termination and low current 3.3V logic supply. The ap1084t33l-u is also well suited for other applications such as VGA cards. The ap1084t33l-u is guaranteed to have lower than 1.4V dropout at full load current making it ideal to provide well-regulated outputs of 1.25 to 3.3V with 4.7 to 12V input supply.

Parametrics

ap1084t33l-u absolute maximum ratings: (1)Vin DC Supply Voltage: -0.3 to 12 V; (2)TST Storage Temperature: -65 to +150 °C; (3)TOP Operating Junction Temperature Range: 0 to +125°C; (4)TM Maximum Junction Temperature: 150°C.

Features

ap1084t33l-u features: (1)1.4V Maximum Dropout at Full Load Current; (2)Built-in Thermal Shutdown; (3)Output Current Limiting; (4)Adjustable Output Voltage or Fixed 1.5V, 1.8V, 2.5V, 3.3V, 5.0V; (5)Fast Transient Response; (6)Good Noise Rejection; (7)Lead-Free Package: TO252-3L, TO263-3L, and TO220-3L; (8)TO252-3L: Available in “Green” Molding Compound (No Br, Sb)(Note 1); (9)Lead Free Finish/RoHS Compliant for Lead Free products (Note 2).
