TLC372CPS

TLC372CPS, lin CMOS dual differential comparator, 2 V, 5 mA, 150 μA, 1012 Ω, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.35~0.35 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1695 :	0.35 / Piece

PartNumber:: TLC372CPS

Brand:: Texas Instruments - TI | Pack: | D/C: 06+

Availability:: Supply Ability: 3/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-20

From Other Seller

Part Number:TLC372CPS
US $0.35 - 0.35
Quantity:

piece

Product Summary

The TLC372CPS is a lin CMOS dual differential comparator. The TLC372CPS is fabricated using LinCMOS technology and consists of two independent voltage comparators, each designed to operate from a single power supply. Operation from dual supplies is also possible if the difference between the two supplies is 2 V to 18 V. The TLC372CPS has internal electrostatic discharge (ESD) protection circuits and has been classified with a 1000-V ESD rating using human body model testing. However, care should be exercised in handling this device as exposure to ESD may result in a degradation of the device parametric performance.

Parametrics

TLC372CPS absolute maximum ratings: (1)Supply voltage, VDD: 18 V; (2)Differential input voltage, VID: ±18 V; (3)Input voltage range, VI: −0.3 V to 18 V; (4)Output voltage, VO: 18 V; (5)Input current, II: ±5 mA; (6)Output current, IO: 20 mA; (7)Duration of output short circuit to ground: unlimited; (8)Operating free-air temperature range, TA: 0°C to 70°C; (9)Storage temperature range: -65°C to 150°C; (10)Case temperature for 60 seconds: FK package: 260°C; (11)Lead temperature 1,6 mm (1/16 inch)from case for 10 seconds: D, P, or PW package: 260°C; (12)Lead temperature 1,6 mm (1/16 inch)from case for 60 seconds: JG or U package: 300°C.

Features

TLC372CPS features: (1)Single or Dual-Supply Operation; (2)Wide Range of Supply Voltages 2 V to 18 V; (3)Low Supply Current Drain 150 μA Typ at 5 V; (4)Fast Response Time: 200 ns Typ for TTL-Level Input Step; (5)Built-in ESD Protection; (6)High Input Impedance: 1012 Ω Typ; (7)Extremely Low Input Bias Current 5 pA Typ; (8)Ultrastable Low Input Offset Voltage; (9)Input Offset Voltage Change at Worst-Case Input Conditions Typically 0.23 μV/Month, Including the First 30 Days; (10)Common-Mode Input Voltage Range Includes Ground; (11)Output Compatible With TTL, MOS, and CMOS; (12)Pin-Compatible With LM393.
