TDA7449

TDA7449, balance processor, 10.5 V, 7 mA, 90 dB, ssop

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.20~1.20 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1796 :	1.20 / Piece

PartNumber:: TDA7449

Brand:: STMicroelectronics - ST | Pack: | D/C: 07+

Availability:: Supply Ability: 3/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-21

From Other Seller

Part Number:TDA7449
US $1.20 - 1.20
Quantity:

piece

Product Summary

The TDA7449 is a volume tone (bass and treble) balance (Left/Right) processor for quality audio applications in TV systems. Selectable input gain is provided. Control of all the functions is accomplished by serial bus. The AC signal setting is obtained by resistor networks and switches combined with operational amplifiers. Thanks to the used BIPOLAR/CMOS Technology, Low Distortion, Low Noise and DC stepping are obtained.

Parametrics

TDA7449 absolute maximum ratings: (1)VS Operating Supply Voltage: 10.5 V; (2)Tamb Operating Ambient Temperature: 0 to 70 °C; (3)Tstg Storage Temperature Range: -55 to 150 °C; (4)IS Supply Current: 7 mA; (5)SVR Ripple Rejection: 60 to 90 dB.

Features

TDA7449 features: (1)input multiplexer 2 stereo inputs, selectable input gain for optimal adaptation to different sources; (2)one stereo output; (3)treble, and bass control in 2.0db steps; (4)volume control in 1.0db steps; (5)two speaker attenuators: – two independent speaker control in 1.0db steps for balance facility – independent mute function; (6)all function are programmable via serial bus.
