PCF8598C-2P/02

PCF8598C-2P/02, Electrically Erasable Programmable Read Only Memory, 6.5 V, 10 mA, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.50~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10000 :	0.50 / Piece

PartNumber:: PCF8598C-2P/02

Brand:: Philips Electronics India Limited - PHILIPS | Pack: SOP | D/C: 05+

Availability:: Supply Ability: 4/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-21

From Other Seller

Part Number:PCF8598C-2P/02
US $0.50 - 0.50
Quantity:

piece

Product Summary

The PCF8598C-2P/02 is a floating gate Electrically Erasable Programmable Read Only Memory (EEPROM) with 2, 4 and 8 kbits (256, 512 and 1024 8-bit). By using an internal redundant storage code it is fault tolerant to single bit errors. This feature of the PCF8598C-2P/02 dramatically increases the reliability compared to conventional EEPROMs. Power consumption is low due to the full CMOS technology used. The programming voltage is generated on-chip, using a voltage multiplier.

Parametrics

PCF8598C-2P/02 absolute maximum ratings: (1)VDD supply voltage: -0.3 to +6.5 V; (2)VI input voltage on any input pin > 500 W VSS: - 0.8 to +6.5 V; (3)II input current on any input pin: 1 mA; (4)IO output current: 10 mA; (5)Tstg storage temperature: -65 to +150 °C; (6)Tamb operating ambient temperature: -40 to +85 °C.

Features

PCF8598C-2P/02 features: (1)Single supply with full operation down to 2.5 V; (2)On-chip voltage multiplier; (3)Serial input/output I2C-bus; (4)Internal timer for writing (no external components); (5)Power-on-reset; (6)High reliability by using a redundant storage code; (7)Endurance: 1000000 Erase/Write (E/W)cycles at Tamb = 22 °C; (8)10 years non-volatile data retention time.
