OP291

OP291, amplifier, 3 MHz, 3 volt, 700 μV, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.50~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1500 :	0.50 / Piece

PartNumber:: OP291

Brand:: Analog Devices - ADI | Pack: SOP | D/C: 06+

Availability:: Supply Ability: 4/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-17

From Other Seller

Part Number:OP291
US $0.50 - 0.50
OP291GSZ-REEL

US $2.20 - 4.02 / Piece
(0) Remove
Quantity:

piece

Product Summary

The OP291 is a single, dual and quad micropower, single-supply, 3 MHz bandwidth amplifier featuring rail-to-rail inputs and outputs. It is guaranteed to operate from a 3 volt single supply as well as ±5 volt dual supplies. Fabricated on Analog Devices CBCMOS process, the OP291 has a unique input stage that allows the input voltage to safely extend 10 volts beyond either supply without any phase inversion or latch-up. The output voltage swings to within millivolts of the supplies and continues to sink or source current all the way to the supplies. The applications of the OP291 include Industrial Process Control, Battery Powered Instrumentation, Power Supply Control and Protection, Telecom, Remote Sensors, Low Voltage Strain Gage Amplifiers, DAC Output Amplifier.

Parametrics

OP291 absolute maximum ratings: (1)Supply Voltage: +16 V; (2)Input Voltage: GND to VS + 10 V; (3)Differential Input Voltage: 7 V; (4)Output Short-Circuit Duration to GND: Indefinite; (5)Storage Temperature Range P, S, RU Packages: –65℃ to +150℃; (6)Operating Temperature Range OP191/OP291/OP491G: –40℃ to +125℃; (7)Junction Temperature Range P, S, RU Packages: –65℃ to +150℃; (8)Lead Temperature Range (Soldering 60 sec): +300℃.

Features

OP291 features: (1)Single-Supply Operation: 2.7 V to 12 V; (2)Wide Input Voltage Range; (3)Rail-to-Rail Output Swing; (4)Low Supply Current: 300 μA/Amp; (5)Wide Bandwidth: 3 MHz; (6)Slew Rate: 0.5 V/μs; (7)Low Offset Voltage: 700 μV; (8)No Phase Reversal.
