MIC5239-3.3YM

MIC5239-3.3YM, regulator, 23μA, 350mV, 1.5kV, 500mA, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.50~1.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10000 :	1.50 / Piece

PartNumber:: MIC5239-3.3YM

Brand:: Micrel Semiconductor - Micrel | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 4/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-04

From Other Seller

Part Number:MIC5239-3.3YM
US $1.50 - 1.50
Quantity:

piece

Product Summary

The MIC5239-3.3YM is a low quiescent current, μCap low-dropout regulator. With a maximum operating input voltage of 30V and a quiescent current of 23μA, the MIC5239-3.3YM is ideal for supplying keep-alive power in systems with high voltage batteries. Capable of 500mA output, it has a dropout voltage of only 350mV. The MIC5239-3.3YM can provide high output current for applications such as USB.

Parametrics

MIC5239-3.3YM absolute maximum ratings: (1)Supply Voltage (VIN): –20V to +32V; (2)Enable Input Voltage (VEN): –0.3V to +32V; (3)Power Dissipation (PD)(3): Internally Limited; (4)Junction Temperature (TJ): –40 to +125℃; (5)Storage Temperature (TS):–65 to +150℃; (6)Lead Temperature (soldering, 5 sec.): 260℃; (7)ESD Rating, SOT-23-3L: 2kV; (8)ESD Rating, MSOP-8L: 1.5kV; (9)Supply Voltage (VIN): 2.3V to 30V; (10)Enable Input Voltage (VEN): 0V to 30V; (11)Junction Temperature (TJ):–40 to +125℃; (12)Package Thermal Resistance, MSOP: 80℃/W; (13)Package Thermal Resistance, SOT-223: 50℃/W.

Features

MIC5239-3.3YM features: (1)Ultra-low quiescent current (IQ = 23μA @IO = 100μA); (2)Continuous 500mA output current; (3)Wide input range: 2.3V to 30V; (4)Low dropout voltage: 350mV @500mA; (5)±1.0% initial output accuracy; (6)Stable with ceramic or tantalum output capacitor; (7)Logic compatible enable input; (8)Low output voltage error flag indicator; (9)Overcurrent protection; (10)Thermal shutdown; (11)Reverse-leakage protection; (12)Reverse-battery protection; (13)High-power SOIC-8, MSOP-8 and SOT-223 packages.
