LP3981ILDX-2.8

LP3981ILDX-2.8, CMOS voltage regulator, 300 mA, 2.5 V, 2 kV, 2.5 W, QFN

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.50~1.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10000 :	1.50 / Piece

PartNumber:: LP3981ILDX-2.8

Brand:: National Semiconductor - NS | Pack: QFN | D/C: 05+

Availability:: Supply Ability: 4/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-20

From Other Seller

Part Number:LP3981ILDX-2.8
US $1.50 - 1.50
Quantity:

piece

Product Summary

The LP3981ILDX-2.8 is a micropower, 300mA ultra low-dropout CMOS voltage regulator. Power supply rejection is better than 60 dB at low frequencies. This high power supply rejection is maintained down to lower input voltage levels common to battery operated circuits. The LP3981ILDX-2.8 is ideal for mobile phone and similar battery powered wireless applications. It provides up to 300 mA, from a 2.5V to 6V input, consuming less than 1μA in disable mode. Applications are (1)CDMA cellular handsets; (2)Wideband CDMA cellular handsets; (3)GSM cellular handsets; (4)Portable informatioappliances; (5)Tiny 3.3V ± 5% to 2.5V, 300mA converter.

Parametrics

LP3981ILDX-2.8 absolute maximum ratings: (1)VIN, VEN: -0.3 to 6.5V; (2)VOUT, VOUT-SENSE: -0.3 to VIN + 0.3, Max 6.5V; (3)Junction Temperature: 150°C; (4)Storage Temperature: -65°C to +150°C; (5)Lead Temp; (6)Pad Temp; (7)Power Dissipation (Note 3)θJA (MSOP-8): 210°C/W; (8)Power Dissipation (Note 3)θJA (LLP-6): 50°C/W; (9)Maximum Power Dissipation at 25°C MSOP-8: 595mW; (10)Maximum Power Dissipation at 25° LLP-6: 2.5W; (11)ESD Rating(Note 4)Human Body Model: 2kV; (12)ESD Rating(Note 4)Machine Model: 200V.

Features

LP3981ILDX-2.8 features: (1)Small, space saving MSOP-8; (2)Low Thermal Resistance iLLP-6 package gives excellent power capability; (3)Logic controlled enable; (4)Stable with ceramic and high quality tantalum capacitors; (5)Fast turn-on; (6)Thermal shutdowand short-circuit current limit.
