AT25640A-10PU

AT25640A-10PU, SPI Serial EEPROM, 7.0V, 5.0 mA, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~1.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10000 :	1.00 / Piece

PartNumber:: AT25640A-10PU

Brand:: ATMEL Corporation - ATMEL | Pack: SOP | D/C: 09+

Availability:: Supply Ability: 4/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-25

From Other Seller

Part Number:AT25640A-10PU
US $1.00 - 1.00
Quantity:

piece

Product Summary

The AT25640A-10PU is a SPI Serial EEPROM. It provides 65536 bits of serial electrically-erasable programmable read-only memory (EEPROM) organized as 8192 words of 8 bits each. The AT25640A-10PU is optimized for use in many automotive applications where low-power and low-voltage operation are essential. The AT25640A-10PU is available in space-saving 8-lead PDIP, 8-lead JEDEC SOIC and 8-lead TSSOP packages.

Parametrics

AT25640A-10PU absolute maximum ratings: (1)Operating Temperature:-40℃ to +125℃; (2)Storage Temperature:-65℃ to +150℃; (3)Voltage on Any Pin with Respect to Ground:-1.0V to +7.0V; (4)Maximum Operating Voltage:6.25V; (5)DC Output Current:5.0 mA.

Features

AT25640A-10PU features: (1)Serial Peripheral Interface (SPI) Compatible; (2)Supports SPI Modes 0 (0,0) and 3 (1,1): Data Sheet Describes Mode 0 Operation; (3)Medium-voltage and Standard-voltage Operation: 2.7 (VCC = 2.7V to 5.5V); (4)Extended Temperature Range:–40℃ to 125℃; (5)5.0 MHz Clock Rate; (6)32-byte Page Mode; (7)Block Write Protection: Protect 1/4, 1/2, or Entire Array; (8)Write Protect (WP) Pin and Write Disable Instructions for Both Hardware and Software Data Protection; (9)Self-timed Write Cycle (2 ms [5V] typical); (10)High Reliability: Endurance: One Million Write Cycles, Data Retention: 100 Years; (11)8-lead PDIP, 8-lead JEDEC SOIC Packages and 8-lead TSSOP Packages.
