Product Summary

The 74lvth16244mtdx is a Low Voltage16-Bit Buffer/Line Driver. The 74lvth16244mtdx contains sixteen non-inverting buffers with 3-STATE outputs designed to be employed as a memory and address driver, clock driver, or bus oriented transmitter/receiver. The 74lvth16244mtdx is nibble controlled. Individual 3-STATE control inputs can be shorted together for 8-bit or 16-bit operation. The 74lvth16244mtdx data inputs include bushold, eliminating the need for external pull-up resistors to hold unused inputs. These buffers and line drivers are designed for low-voltage (3.3V) VCC applications, but with the capability to provide a TTL interface to a 5V environment. The 74lvth16244mtdx is fabricated with an advanced BiCMOS technology to achieve high speed operation similar to 5V ABT while maintaining a low power dissipation.

Parametrics

74lvth16244mtdx absolute maximum ratings: (1)Supply Voltage: -0.5 to +4.6 V; (2)DC Input Voltage: -0.5 to +7.0 V; (3)Output Voltage -0.5 to +7.0 V; (4)DC Input Diode Current: -50 mA; (5)DC Output Current: 64 mA; (6)DC Supply Current per Supply Pin: ±64 mA; (7)DC Ground Current per Ground Pin: ±128 mA; (8)Storage Temperature: -65 to +150 ℃.

Features

74lvth16244mtdx features: (1)Input and output interface capability to systems at 5V VCC; (2)Bushold data inputs eliminate the need for external pull-up resistors to hold unused inputs (74LVTH16244), also available without bushold feature (74LVT16244).; (3)Live insertion/extraction permitted; (4)Power Up/Down high impedance provides glitch-free bus loading; (5)Outputs source/sink -32 mA/+64 mA; (6)Functionally compatible with the 74 series 16244; (7)Latch-up performance exceeds 500 mA.
