Product Summary
The 74abt16245bdl-t is a high-performance BiCMOS device. The 74abt16245bdl-t combines low static and dynamic power dissipation with high speed and high output drive. The 74abt16245bdl-t is a dual octal transceiver featuring non-inverting 3-State bus compatible outputs in both send and receive directions. The control function implementation minimizes external timing requirements. The 74abt16245bdl-t features two Output Enable (1OE, 2OE) inputs for easy cascading and two Direction (1DIR, 2DIR) inputs for direction control.
Parametrics
74abt16245bdl-t absolute maximum ratings: (1)VCC, DC supply voltage: –0.5 to +7.0 V; (2)IIK, DC input diode current: –18 mA; (3)VI, DC input voltage: –1.2 to +7.0 V; (4)IOK, DC output diode current: –50 mA; (5)VOUT, DC output voltage:e –0.5 to +5.5 V; (6)IOUT, DC output current: 128mA; (7)Tstg, Storage temperature range: –65 to 150℃.
Features
74abt16245bdl-t features: (1)16-bit bidirectional bus interface; (2)Power-up 3-State; (3)Multiple VCC and GND pins minimize switching noise; (4) 3-State buffers; (5)Output capability: +64 mA / –32 mA; (6)Latch-up protection exceeds 500 mA per JEDEC Std 17; (7)Live insertion/extraction permitted; (8)ESD protection exceeds 2000 V per MIL STD 883 Method 3015 and 200 V per Machine Model; (9)74ABTH16245B incorporates bus-hold data inputs which eliminate the need for external pull-up resistors to hold unused inputs; (10)Bus-hold data inputs eliminate the need for external pull-up resistors to hold unused inputs.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 74ABT16245BDL-T |
NXP Semiconductors |
Bus Transceivers 16-BIT OCT XCVR W/DIR PIN 3-S |
Data Sheet |
Negotiable |
|
||||||||||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||||||||||
 |
74ABT00 |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||||
 |
74ABT00D,112 |
NXP Semiconductors |
Gates (AND / NAND / OR / NOR) QUAD 2-IN NAND GATE |
Data Sheet |
|
|
||||||||||||
 |
74ABT00D,118 |
|
IC 2-IN GATE NAND QUAD 14SOIC |
Data Sheet |
|
|
||||||||||||
|
74ABT00DB,112 |
NXP Semiconductors |
Gates (AND / NAND / OR / NOR) QUAD 2-INPUT NAND |
Data Sheet |
|
|
||||||||||||
 |
74ABT00DB,118 |
|
IC 2-IN GATE NAND QUAD 14-SSOP |
Data Sheet |
|
|
||||||||||||
 |
74ABT00N,112 |
NXP Semiconductors |
Gates (AND / NAND / OR / NOR) QUAD 2-INPUT NAND |
Data Sheet |
|
|
||||||||||||
