1N5820RLG

1n5820rlg, schottky barrier rectifier, 24 V, 3.0 A, 60 Hz, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.25~0.25 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 3000 :	0.25 / Piece

PartNumber:: 1N5820RLG

Brand:: ON Semiconductor - ON | Pack: SOP | D/C: 09+

Availability:: Supply Ability: 100/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-11

From Other Seller

Part Number:1N5820RLG
US $0.25 - 0.25
Quantity:

piece

Product Summary

The 1n5820rlg is a schottky barrier rectifier. The 1n5820rlg employs the Schottky Barrier principle in a large area metal−to−silicon power diode. State−of−the−art geometry features chrome barrier metal, epitaxial construction with oxide passivation and metal overlap contact. Ideally suited for use as rectifiers in low−voltage, high−frequency inverters, free wheeling diodes, and polarity protection diodes.

Parametrics

1n5820rlg absolute maximum ratings: (1)Peak Repetitive Reverse Voltage, Working Peak Reverse Voltage, DC Blocking Voltage: 20 V; (2)Non−Repetitive Peak Reverse Voltage VRSM: 24 V; (3)RMS Reverse Voltage VR(RMS): 14 V; (4)Average Rectified Forward Current (Note 1)VR(equiv) 0.2 VR(dc), TL = 95°C (RJA = 28°C/W, P.C. Board Mounting, see Note 5)IO: 3.0 A; (5)Ambient Temperature Rated VR(dc), PF(AV)= 0 RJA = 28°C/W TA: 90 °C; (6)Non−Repetitive Peak Surge Current (Surge applied at rated load conditions, half wave, single phase 60 Hz, TL = 75°C)IFSM: 80 (for one cycle)A; (7)Operating and Storage Junction Temperature Range (Reverse Voltage applied)TJ, Tstg: -65 to +125 °C.

Features

1n5820rlg features: (1)Extremely Low VF; (2)Low Power Loss/High Efficiency; (3)Low Stored Charge, Majority Carrier Conduction; (4)Shipped in plastic bags, 500 per bag; (5)Available in Tape and Reel, 1500 per reel, by adding a RL suffix to the part number; (6)Pb−Free Packages are Available.
