Product Summary
The STTA3006PI is a very high performance series of ultra-fast high voltage power diode from 600V to 1200V. TURBOSWITCH family, drastically cuts losses in both the diode and the associated switching IGBT or MOSFET in all freewheel mode operations and is particularly suitable and efficient in motor control free wheel applicationsand in boosterdiode applications in power factor control circuitries. Packaged either in ISOTOP, DOP3I or SOD93 the STTA3006PI is particularly intended for use on 240V domesticmains.
Parametrics
STTA3006PI absolute maximum ratings: (1)VRRM, repetitive peak reverse voltage: 600 V; (2)VRSM Non repetitive peak reverse voltage: 600 V; (3)IF(RMS), RMS forward current: 50 A; (4)IFRM, repetitive peak forward current tp=5μs F=5kHz square: 300 A; (5)IFSM, surge non repetitiveforward current tp=10ms sinusoidal: 230 A; (6)Tj, maximum operating junction temperature: 150℃; (7)Tstg, storage temperaturerange: -65 to 150℃.
Features
STTA3006PI features: (1)Specifictofreewheelmode operations: freewheel or boosterdiode; (2)Ultra-fast andsoft recovery; (3)Very low overall power losses in both the diode and the companion transistor; (4)High frequency operations; (5)Insulatedpackage: ISOTOP & DOP3I electrical insulation: 2500VRMS.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 STTA3006PI |
Other |
|
Data Sheet |
Negotiable |
|
||||
 |
STTA3006PIRG |
STMicroelectronics |
Rectifiers 30 Amp 600 Volt |
Data Sheet |
Negotiable |
|
||||
