IRFD9210

IRFD9210, MOSFET, 200 V, 0.25 A, 1.0 W, DIP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~1.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10000 :	1.00 / Piece

PartNumber:: IRFD9210

Brand:: International Rectifier - IR | D/C: 05+

Availability:: Supply Ability: 4/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-24

From Other Seller

Part Number:IRFD9210
US $1.00 - 1.00
Quantity:

piece

Product Summary

The IRFD9210 is a power MOSFET. The efficient geometry and unique processing of the IRFD9210 design archieve very low on-state resistance combined with high transconductance and extreme device ruggedness. The 4 pin DIP package is a low cost machine-insertable case style which can be stacked in multiple combinations on standard 0.1" pin centers. The dual drain serves as a thermal link to the mounting surface for power dissipation levels up to 1 W.

Parametrics

IRFD9210 absolute maximum ratings: (1)Drain-Source voltage, VDS: - 200 V; (2)Gate-Source voltage, VGS: ± 20 V; (3)Continuous drain current, VGS at - 10 V, TC = 25 °C, ID: - 0.40 A; TC = 100 °C, ID: - 0.25 A; (4)Pulsed drain current, IDM: - 3.2 A; (5)Linear derating factor: 0.0083 W/°C; (6)Single pulse avalanche energy, EAS: 210 mJ; (7)Repetitive avalanche current, IAR: - 0.40 A; (8)Repetitive avalanche energy, EAR: 0.10 mJ; (9)Maximum power dissipation, TC = 25 °C, PD: 1.0 W; (10)Peak diode recovery dV/dt, dV/dt: - 5.0 V/ns; (11)Operating junction and storage temperature range, TJ, Tstg: - 55 to + 150 °C.

Features

IRFD9210 features: (1)Dynamic dV/dt rating; (2)Repetitive avalanche rated; (3)For automatic insertion; (4)End stackable; (5)P-Channel; (6)Fast switching; (7)Ease of paralleling; (8)Lead (Pb)-free available.
