FDS4685

FDS4685, 40V, P-Channel PowerTrench MOSFET, -8.2A, Fairchild Semiconductor

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.50~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 350000 :	0.50 / Piece

PartNumber:: FDS4685

Brand:: Fairchild Semiconductor - Fairchild | D/C: 12+

Availability:: Supply Ability: 2/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-07

From Other Seller

Part Number:FDS4685
US $0.50 - 0.50
Quantity:

piece

Product Summary

The FDS4685 is a 40V P-Channel PowerTrench MOSFET. The FDS4685 is a rugged gate version of Fairchild Semiconductor’s advanced PowerTrench process. It has been optimized for power management applications requiring a wide range of gate drive voltage ratings (4.5V – 20V). The applications of the FDS4685 include Power management, Load switch, Battery protection.

Parametrics

FDS4685 absolute maximum ratings: (1)VDSS Drain-Source Voltage: –40 V; (2)VGSS Gate-Source Voltage: ±20 V; (3)ID Drain Current - Continuous (Note 1a): –8.2 A; (4)Power Dissipation for Single Operation (Note 1a): 2.5 W; (5)Operating and Storage Junction Temperature Range: –55 to +150℃.

Features

FDS4685 features: (1)–8.2 A, –40 V R DS(ON)= 0.027Ω @ VGS= –10 V; (2)RDS(ON)= 0.035Ω@ VGS= –4.5 V; (3)Fast switching speed; (4)High performance trench technology for extremely low RDS(ON); (5)High power and current handling capability.
