LTV-847

LTV-847, photocoupler, 50 mA, 6 V, 150 mW, DIP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.23~0.23 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 3600 :	0.23 / Piece

PartNumber:: LTV-847

Brand:: Lite-On Technology Corporation - Lite-On | D/C: 11+

Availability:: Supply Ability: 100/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-01

From Other Seller

Part Number:LTV-847
US $0.23 - 0.23
Quantity:

piece

Product Summary

The LTV-847 is a high density mounting type photocoupler. Applications are (1)Computer terminals; (2)System appliances, measuring instruments; (3)Registers, copiers, automatic vending machines; (4)Electric home appliances such as fan heaters, etc; (5)Signal transmission between circuits of different potentials and impedances.

Parametrics

LTV-847 absolute maximum ratings: (1)Input forward current: 50 mA; (2)Input reverse voltage: 6 V; (3)Input power dissipation: 70 mW; (4)Output collector-emitter Voltage: 35 V; (5)Output emitter-collector Voltage: 6 V; (6)Output collector current: 50 mA; (7)Output collector power dissipation: 150 mW; (8)Total power dissipation: 200 mW; (9)Operating temperature: -30 to +100 ℃; (10)Storage temperature: -55 to +125 ℃; (11)Isolation voltage: 5 KVrms; (12)Soldering temperature: 260 ℃.

Features

LTV-847 features: (1)Current transfer ratio (CTR : MIN. 50% at IF=5mA, VCE=5V); (2)High inputoutput isolation voltage: (VISO : 5,000Vrms); (3)Compact dualinline package: 4channel type; (4)UL approved (No. E113898); (5)TUV approved (No. R9653630); (6)CSA approved (No. CA915331); (7)FIMKO approved (No. 202634); (8)NEMKO approved (No. P98101945); (9)DEMKO approved (No. 307857); (10)SEMKO approved (No. 9832157/0103); (11)VDE approved (No. 094722); (12)Options available: Leads with 0.4"(10.16mm)spacing (M Type); Leads bends for surface mounting(S Type); Tape and Reel of Type I for SMD(Add"TA"Suffix); Tape and Reel of Type II for SMD(Add"TA1"Suffix); VDE 0884 approvals (Add"V"Suffix).
