Product Summary
The MOC207R1M is a small outline optocouplers transistor. The MOC207R1M consists of a gallium arsenide infrared emitting diode optically coupled to a monolithic silicon phototransistor detector, in a surface mountable, small outline, plastic package. The MOC207R1M is ideally suited for high density applications, and eliminate the need for throughthe- board mounting. Applications are(1)Feedback control circuits; (2)Interfacing and coupling systems of different potentials and impedances; (3)General purpose switching circuits; (4)Monitor and detection circuits.
Parametrics
MOC207R1M absolute maximum ratings: (1)Forward current – continuous: 60 mA; (2)Forward current – peak (PW = 100 μs, 120 pps): 1.0 A; (3)Reverse voltage: 6.0 V; (4)LED power dissipation @ T A = 25°C: 90 mW; (5)Derate above 25°C: 0.8 mW/°C; (6)Collector-emitter voltage: 70 V; (7)Emitter-collector voltage: 7.0 V; (8)Collector-base voltage: 70 V; (9)Collector current-continuous: 150 mA; (10)Detector power dissipation @ T A = 25°C: 150 mW; (11)Derate above 25°C: 1.76 mW/°C; (12)Input-output isolation voltage (f = 60 Hz, t = 1 minute)(1)(2)(3): 2500 Vac(rms); (13)Total device power dissipation @ T A = 25°C: 250 mW; (14)Derate above 25°C: 2.94 mW/°C; (15)Ambient operating temperature range: -40 to +100 °C; (16)Storage temperature range: -40 to +150 °C.
Features
MOC207R1M features: (1)U.L. Recognized (File #E90700, Volume 2); (2)VDE recognized (File #136616)(add option “V” for VDE approval, i.e, MOC205VM); (3)Closely matched current transfer ratios; (4)Convenient plastic SOIC-8 surface mountable package style; (5)Minimum BV CEO of 70 V guaranteed; (6)Standard SOIC-8 Footprint, with 0.050 lead spacing; (7)High input-output isolation of 2500 V AC(rms)guaranteed.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 MOC207R1M |
Fairchild Semiconductor |
Transistor Output Optocouplers Optocoupler Phototransistor |
Data Sheet |
Negotiable |
|
||||
|
MOC207R1M_Q |
Fairchild Semiconductor |
Transistor Output Optocouplers Optocoupler Phototransistor |
Data Sheet |
Negotiable |
|
||||
