Product Summary
The upc393g2-e2-a is a Low power dual comparator. The upc393g2-e2-a is a dual comparator which is designed to operate from a single power supply over a wide range of voltage. Operation from split power supplies is also possible and the power supply current drain is very low. Further advantage, the input common-mode voltage includes ground, even though operated from a single power supply voltage.
Parametrics
upc393g2-e2-a absolute maximum ratings: (1)Voltage between V+ and V–: –0.3 to +36 V; (2)Differential Input Voltage: ±36 V; (3)Input Voltage: V– –0.3 to V– +36 V; (4)Output Voltage: V– –0.3 to V– +36 V; (5)Power Dissipation: 350 mW; (6)Operating Ambient Temperature: –20 to +80 ℃; (7)Storage Temperature: –55 to + 125 ℃.
Features
upc393g2-e2-a features: (1)Common-mode input voltage range includes V; (2)Low supply current; (3)Open collector output.
