UA78L15ACPK

UA78L15ACPK, integrated-circuit voltage regulator, 35 V, 100 mA, 51 dB, ssop

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.13~0.13 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.13 / Piece

PartNumber:: UA78L15ACPK

Brand:: Texas Instruments - TI | Pack: | D/C: 05+

Availability:: Supply Ability: 1000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-08-02

From Other Seller

Part Number:UA78L15ACPK
US $0.13 - 0.13
Quantity:

piece

Product Summary

The ua78l15acpk is a fixed-voltage integrated-circuit voltage regulator. The ua78l15acpk is designed for a wide range of applications. These applications include on-card regulation for elimination of noise and distribution problems associated with single-point regulation. In addition, they can be used with power-pass elements to make high-current voltage regulators. One of the ua78l15acpk can deliver up to 100 mA of output current. The internal limiting and thermal-shutdown features of these regulators essentially make them immune to overload. When used as a replacement for a Zener diode-resistor combination, an effective improvement in output impedance can be obtained, together with lower bias current.

Parametrics

ua78l15acpk absolute maximum ratings: (1)Input voltage, VI: 35 V; (2)Virtual junction temperature, TJ : 150°C; (3)Storage temperature range, Tstg: −65°C to 150°C; (4)IO Output current: 100 mA; (5)Ripple rejection VI = 6 V to 20 V, f = 120 Hz 25°C: 43 to 51 dB.

Features

ua78l15acpk features: (1)3-Terminal Regulators; (2)Output Current Up To 100 mA; (3)No External Components; (4)Internal Thermal-Overload Protection; (5)Internal Short-Circuit Current Limiting.
