TC7WH34FU

Triple Non-Inverter, -0.5 to 7.0 V, -20 mA, SSOP-8

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.07~0.07 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 3000 :	0.07 / Piece

PartNumber:: TC7WH34FU

Brand:: Toshiba Semiconductor - Toshiba | Pack: | D/C: 09+

Availability:: Supply Ability: 3000/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-22

From Other Seller

Part Number:TC7WH34FU
US $0.07 - 0.07
Quantity:

piece

Product Summary

The tc7wh34fu is a Triple Non-Inverter.

Parametrics

tc7wh34fu absolute maximum ratings: (1)Supply voltage: VCC: -0.5 to 7.0 V ; (2)DC input voltage: VIN: -0.5 to 7.0 V ; (3)DC output voltage: VOUT: -0.5 to VCC+0.5 V ; (4)Input diode current: IIK: -20 mA; (5)Output diode current: IOK: ±20mA; (6)DC output current: IOUT: ±25 mA; (7)DC VCC/GND current: ICC: ±50 mA; (8)Power dissipation: PD: 300mW (SM8), 200mW (US8); (9)Storage temperature: Tstg: -65 to 150 °C; (10)Lead Temperature (10s): TL: 260 °C.

Features

tc7wh34fu features: (1)High speed operation: tpd = 3.8ns (typ.) at VCC = 5V, CL = 15pF; (2)Low power dissipation: ICC = 2μA (max) at Ta = 25°C; (3)High noise immunity: VNIH = VNIL = 28% V CC (min); (4)Operating voltage range: VCC = 2 to 5.5V; (5)Balanced propagation delays: tpLH ≒ tpHL; (6)5.5-V tolerant inputs; (7)Identical pin assignment and function with TC7W34.
