N74F245D

Octal transceiver, 3-State, 4.0ns, 70mA, SOT-163

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.06~0.06 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.06 / Piece

PartNumber:: N74F245D

Brand:: NXP - NXP | Pack: | D/C: 10+

Availability:: Supply Ability: 1000/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-22

From Other Seller

Part Number:N74F245D
US $0.06 - 0.06
Quantity:

piece

Product Summary

The n74f245d is an octal transceiver featuring non-inverting 3-State bus compatible outputs in both transmit and receive directions. The B port outputs are capable of sinking 64mA and sourcing 15mA, producing very good capacitive drive characteristics. The n74f245d features an Output Enable (OE) input for easy cascading and Transmit/Receive (T/R) input for direction control. The 3-State outputs, B0–B7, have been designed to prevent output bus loading if the power is removed from the n74f245d.

Parametrics

n74f245d absolute maximum ratings: (1)Supply voltage: –0.5 to +7.0 V; (2)Input voltage: –0.5 to +7.0 V; (3)Input current: –30 to +5 mA; (4)Voltage applied to output in High output state: –0.5 to +5.5 V; (5)Current applied to output in Low output state: A0–A7: 48 mA; (6)Current applied to output in Low output state: B0–B7: 128 mA; (7)Operating free-air temperature range: 0 to +70 °C; (8)Storage temperature range: –65 to +150 °C.

Features

n74f245d features: (1)Octal bidirectional bus interface; (2)3-State buffer outputs sink 64mA; (3)15mA source current; (4)Outputs are placed in high impedance state during power-off conditions.
