MM74HC595MX

MM74HC595MX, high speed shift register, 7.0 V, 20 mA, 600 mW, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.09~0.09 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 2500 :	0.09 / Piece

PartNumber:: MM74HC595MX

Brand:: Freescale Semiconductor, Inc - Freescale | Pack: | D/C: 05+

Availability:: Supply Ability: 2500/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-25

From Other Seller

Part Number:MM74HC595MX
US $0.09 - 0.09
Quantity:

piece

Product Summary

The MM74HC595MX is a high speed shift register. It utilizes advanced silicon-gate CMOS technology. The MM74HC595MX possesses the high noise immunity and low power consumption of standard CMOS integrated circuits, as well as the ability to drive 15 LS-TTL loads. The MM74HC595MX contains an 8-bit serial-in, parallel-out shift register that feeds an 8-bit D-type storage register. The storage register has 8 3-STATE outputs. Separate clocks are provided for both the shift register and the storage register. The shift register has a direct-overriding clear, serial input, and serial output (standard) pins for cascading. Both the shift register and storage register use positive-edge triggered clocks. If both clocks are connected together, the shift register state will always be one clock pulse ahead of the storage register.

Parametrics

MM74HC595MX absolute maximum ratings: (1)Supply voltage (VCC): -0.5 to +7.0 V; (2)DC input voltage (VIN): -1.5 to VCC +1.5 V; (3)DC output voltage (VOUT): -0.5 to VCC +0.5 V; (4)Clamp diode current (IIK, IOK): ±20 mA; (5)DC output current, per pin (IOUT): ±35 mA; (6)DC VCC or GND current, per pin (ICC): ±70 mA; (7)Storage temperature range (TSTG): -65°C to +150°C; (8)Power dissipation (PD)(Note 3): 600 mW; (9)S.O. package only: 500 mW; (10)Lead temperature (TL)(Soldering 10 seconds): 260°C.

Features

MM74HC595MX features: (1)Low quiescent current: 80 mA maximum (74HC Series); (2)Low input current: 1 mA maximum; (3)8-bit serial-in, parallel-out shift register with storage; (4)Wide operating voltage range: 2V–6V; (5)Cascadable; (6)Shift register has direct clear; (7)Guaranteed shift frequency: DC to 30 MHz.
