MM74HC14MX

MM74HC14MX, hex inverting schmitt trigger, 7.0 V, 20 mA, 500 mW, BGA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.08~0.08 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 5000 :	0.08 / Piece

PartNumber:: MM74HC14MX

Brand:: Freescale Semiconductor, Inc - Freescale | Pack: BGA | D/C: 10+

Availability:: Supply Ability: 5000/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-22

From Other Seller

Part Number:MM74HC14MX
US $0.08 - 0.08
Quantity:

piece

Product Summary

The MM74HC14MX is a hex inverting schmitt trigger. The MM74HC14MX utilizes advanced silicon-gate CMOS technology to achieve the low power dissipation and high noise immunity of standard CMOS, as well as the capability to drive 10 LS-TTL loads. The 74HC logic family is functionally and pinout compatible with the standard 74LS logic family. All inputs are protected from damage due to static discharge by internal diode clamps to VCC and ground.

Parametrics

MM74HC14MX absolute maximum ratings: (1)Supply Voltage (VCC): -0.5 to +7.0 V; (2)DC Input Voltage (VIN): -1.5 to VCC +1.5 V; (3)DC Output Voltage (VOUT): -0.5 to VCC +0.5 V; (4)Clamp Diode Current (IIK, IOK): ±20 mA; (5)DC Output Current, per pin (IOUT): ±25 mA; (6)DC VCC or GND Current, per pin (ICC): ±50 mA; (7)Storage Temperature Range (TSTG): -65qC to +150 ℃; (8)Power Dissipation (PD)(Note 3): 600 mW; (9)Power Dissipation (PD)S.O. Package only: 500 mW; (10)Lead Temperature (TL)(Soldering 10 seconds): 260 ℃.

Features

MM74HC14MX features: (1)Typical propagation delay: 13 ns; (2)Wide power supply range: 2–6V; (3)Low quiescent current: 20 PA maximum (74HC Series); (4)Low input current: 1 PA maximum; (5)Fanout of 10 LS-TTL loads; (6)Typical hysteresis voltage: 0.9V at VCC 4.5V.
