M74HC221M1R

M74HC221M1R, dual monostable multivibrator, 7 V, 20 mA, 150 ns, SOIC

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.24~0.24 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 200 :	0.24 / Piece

PartNumber:: M74HC221M1R

Brand:: STMicroelectronics - ST | Pack: SOIC | D/C: 04+

Availability:: Supply Ability: 100/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-07

From Other Seller

Part Number:M74HC221M1R
US $0.24 - 0.24
Quantity:

piece

Product Summary

The M74HC221M1R is a high speed CMOS MONOSTABLE multivibrators fabricated with silicon gate C2MOS technology. The M74HC221M1R achieves the high speed operation similar to equivalent LSTTL while maintaining theCMOS low power dissipation. The M74HC221M1R is two trigger inputs, AINPUT (negative edge) and B INPUT (positive edge). Triggering on the B input occurs at a particular voltage threshold and is not related to the rise and fall time of the applied pulse.

Parametrics

M74HC221M1R absolute maximum ratings: (1)Supply Voltage: -0.5 to +7 V; (2)DC Input Voltage: -0.5 to VCC + 0.5 V; (3)DC Output Voltage: -0.5 to VCC + 0.5 V; (4)IDC Input Diode Current: ± 20 mA; (5)DC Output Diode Current: ± 20 mA; (6)DC Output Source Sink Current Per Output Pin: ± 25 mA; (7)DC VCC or Ground Current: ± 50 mA; (8)Power Dissipation: 500 mW; (9)Storage Temperature: -65 to +150 ℃; (10)Lead Temperature (10 sec): 300 ℃.

Features

M74HC221M1R features: (1)High speed tPD = 25 ns (Typ)at Vcc = 5V; (2)Lowpower dissipation standbystateicc=4 mA (max.)AT TA=25°C activestateicc =700mA (max.)AT Vcc=5V; (3)High noise immunity Vnih = VNIL = 28 % VCC (min.); (4)Output drive capability 10 lsttl loads; (5)Symmetrical output impedance Ioh = Iol = 4 mA (min.); (6)Balancedpropagation delays tplh = tphl; (7)Wide operating voltage range Vcc (opr)= 2 V TO 6 V; (8)Wide output pulse width range twout = 150 ns ~ 60 s over at Vcc = 4.5 V; (9)Pin and function compatible with 54/74LS221.
