LT1490CS8

LT1490CS8, op amps, 44V, 25mA, 200kHz, SOIC

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.38~1.38 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 200 :	1.38 / Piece

PartNumber:: LT1490CS8

Brand:: LT Electronics Co., Ltd. - LT | Pack: SOIC | D/C: 99+

Availability:: Supply Ability: 100/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-04

From Other Seller

Part Number:LT1490CS8
US $1.38 - 1.38
Quantity:

piece

Product Summary

The lt1490cs8 op amps operates on all single and split supplies with a total voltage of 2V to 44V drawing only 40mA of quiescent current per amplifier. The lt1490cs8 is reverse supply protected; they draw no current for reverse supply up to 18V. The input range of the lt1490cs8 includes both supplies and the output swings to both supplies. Applications are (1)Battery- or Solar-Powered Systems Portable Instrumentation, Sensor Conditioning; (2)Supply Current Sensing; (3)Battery Monitoring; (4)Micropower Active Filters; (5)4mA to 20mA Transmitters.

Parametrics

lt1490cs8 absolute maximum ratings: (1)Total Supply Voltage (V+ to V–): 44V; (2)Input Differential Voltage : 44V; (3)Input Current : ±25mA; (4)Operating Temperature Range : – 40°C to 85°C; (5)Junction Temperature : 150°C; (6)Specified Temperature Range (Note 2): – 40°C to 85°C; (7)Storage Temperature Range : –65°C to 150°C; (8)Lead Temperature (Soldering, 10 sec): 300°C.

Features

lt1490cs8 features: (1)Rail-to-Rail Input and Output; (2)Single Supply Input Range: –0.4V to 44V; (3)Micropower: 50mA/Amplifier Max; (4)Specified o3V, 5V and ±15V Supplies; (5)High Output Current: 20mA; (6)Output Drives 10,000pF with Output Compensation; (7)Reverse Battery Protectioto 18V; (8)No Supply Sequencing Problems; (9)High Voltage Gain: 1500V/mV; (10)High CMRR: 98dB; (11)No Phase Reversal; (12)GaiBandwidth Product: 200kHz.
