LM833DR2G

lm833dr2g, operational amplifier, SOP, ±15V, 15MHz, 5mA, 500mW

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.13~0.13 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.13 / Piece

PartNumber:: LM833DR2G

Brand:: ON Semiconductor - ON | Pack: | D/C: 10+

Availability:: Supply Ability: 1000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-08-09

From Other Seller

Part Number:LM833DR2G
US $0.13 - 0.13
Quantity:

piece

Product Summary

The lm833dr2g is a dual general purpose operational amplifier designed with particular emphasis on performance in audio systems. This dual amplifier IC utilizes new circuit and processing techniques to deliver low noise, high speed and wide band-width without increasing external components or decreasing stability. The lm833dr2g is internally compensated for all closed loop gains and is therefore optimized for all preamp and high level stages in PCM and HiFi systems. The lm833dr2g is pin-for-pin compatible with industry standard dual operational amplifiers.

Parametrics

lm833dr2g absolute maximum ratings: (1)Supply Voltage VCC–VEE: 36V; (2)Differential Input Voltage, VI: ±30V; (3)Input Voltage Range, VIC: ±15V; (4)Power Dissipation, PD: 500 mW; (5)Operating Temperature Range, TOPR: -40 ～ 85℃; (6)Storage Temperature Range, TSTG: -60 ～ 150℃; (7)Soldering Information: 260℃; (8)Vapor Phase (60 seconds): 215℃; (9)Infrared (15 seconds): 220℃; (10)ESD tolerance: 1600V.

Features

lm833dr2g features: (1)Wide dynamic range: >140dB; (2)Low input noise voltage: 4.5nV/√Hz; (3)High slew rate: 7 V/μs (typ); 5V/μs (min); (4)High gain bandwidth: 15MHz (typ); 10MHz (min); (5)Wide power bandwidth: 120KHz; (6)Low distortion: 0.002%; (7)Low offset voltage: 0.3mV; (8)Large phase margin: 60°; (9)Available in 8 pin MSOP package.
