LM4860MX

LM4860MX, audio power amplifier, 6.0 V, 1 W, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.62~0.62 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 3397 :	0.62 / Piece

PartNumber:: LM4860MX

Brand:: National Semiconductor - NS | Pack: SOP | D/C: 02+

Availability:: Supply Ability: 100/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-07

From Other Seller

Part Number:LM4860MX
US $0.62 - 0.62
Quantity:

piece

Product Summary

The LM4860MX is a bridge-connected audio power amplifier capable of delivering 1W of continuous average power to an 8W load with less than 1% (THD+N) over the audio spectrum from a 5V power supply. Boomer audio power amplifiers were designed specifically to provide high quality output power with a minimal amount of external components using surface mount packaging. Since the LM4860MX does not require output coupling capacitors, bootstrap capacitors or snubber networks, it is optimally suited for low-power portable systems. The LM4860MX features an externally controlled, low-power consumption shutdown mode, as well as an internal thermal shutdown protection mechanism. It also includes two headphone control inputs and a headphone sense output for external monitoring. The unity-gain stable LM4860 can be configured by external gain setting resistors for differential gains of 1 to 10 without the use of external compensation components.

Parametrics

LM4860MX absolute maximum ratings: (1)Supply Voltage: 6.0V; (2)Storage Temperature: 65℃ to +150℃; (3)Input Voltage: 0.3V to VDD + 0.3V; (4)Power Dissipation: Internally limited; (5)ESD Susceptibility: 3000V; (6)ESD Susceptibility: 250V; (7)Junction Temperature: 150℃; (8)Soldering Small Outline Package Vapor Phase (60 sec.): 215℃; (9)Soldering Small Outline Package Infrared (15 sec.): 220℃.

Features

LM4860MX features: (1)No output coupling capacitors, bootstrap capacitors, or snubber circuits are necessary; (2)Small Outline (SO) power packaging; (3)Compatible with PC power supplies; (4)Thermal shutdown protection circuitry; (5)Unity-gain stable; (6)External gain configuration capability; (7)Two headphone control inputs and headphone sensing output.
