LM431BCMX, 3-terminal adjustable shunt regulator, 150 mA, 0.78W, SOIC

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.16~0.16 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 3570 :	0.16 / Piece

PartNumber:: LM431BCMX

Brand:: National Semiconductor - NS | Pack: SOIC | D/C: 99+

Availability:: Supply Ability: 100/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-04

From Other Seller

Part Number:LM431BCMX
US $0.16 - 0.16
Quantity:

piece

Product Summary

The LM431BCMX is a 3-terminal adjustable shunt regulator with guaranteed temperature stability over the entire temperature range of operation. The LM431BCMX is now available in a chip sized package (4-Bump micro SMD) using National’s micro SMD package technology. The output voltage may be set at any level greater than 2.5V (VREF) up to 36V merely by selecting two external resistors that act as a voltage divided network. Due to the sharp turn-on characteristics, the LM431BCMX is an excellent replacement for many zener diode applications.

Parametrics

LM431BCMX absolute maximum ratings: (1)Storage Temperature Range: -65℃ to +150℃; (2)Operating Temperature Range Commercial: 0℃ to +70℃; (3)Soldering Information Infrared or Convection (20 sec.): 235℃; (4)Wave Soldering (10 sec.): 260℃ (lead temp.); (5)Cathode Voltage: 37V; (6)Continuous Cathode Current: 10 mA to +150 mA; (7)Reference Voltage: -0.5V; (8)Reference Input Current: 10 mA; (9)Internal Power Dissipation: 0.78W.
