LD1117AS18TR

LD1117AS18TR, To, adjustable positive voltage regulator, 12 W, 15 V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.11~0.11 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 2500 :	0.11 / Piece

PartNumber:: LD1117AS18TR

Brand:: STMicroelectronics - ST | Pack: | D/C: 09+

Availability:: Supply Ability: 2500/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-30

From Other Seller

Part Number:LD1117AS18TR
US $0.11 - 0.11
Quantity:

piece

Product Summary

The ld1117as18tr is a low drop voltage regulator able to provide up to 1A of output current, available even in adjustable version (Vref=1.25V). Concerning fixed versions, are offered the following Output Voltages: 1.2V, 1.8V, 2.5V, 2.85V, 3.3V and 5.0V. The 2.85V type is ideal for SCSI-2 lines active termination. The device is supplied in: SOT-223, DPAK, D2PAK/A and TO-220. Surface mount packages optimize the thermal characteristics even offering a relevant space saving effect. High efficiency is assured by NPN pass transistor. Only a very common 10μF minimum capacitor is needed for stability. Only chip trimming allows the regulator to reach a very tight output voltage tolerance, within ±2% at 25°C.

Parametrics

ld1117as18tr absolute maximum ratings: (1)DC Input Voltage: 15 V; (2)Power Dissipation: 12 W; (3)Storage Temperature Range: -40 to +150°C; (4)Operating Junction Temperature Range: 0 to +125°C.

Features

ld1117as18tr features: (1)Low dropout voltage; (2)Very low quiescent current; (3)Output current up to 1A; (4)Fixed output voltage of: 1.2V, 1.8V, 2.5V, 2.85V, 3.3V, 5.0V; (5)Adjustable version availability; (6)Internal current and thermal limit; (7)Only 10 μF for stability; (8)Available in ±2% (at 25°C) and 4% in full temperature range; (9)High supply voltage rejection:– 80dB typ. at 25°C); (10)Temperature range: 0°C to 125°C.
