ISL6612ACBZ-T

MOSFET driver, 12V, 2MHz, SOP, isl6612acbz-t

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.46~0.46 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1300 :	0.46 / Piece

PartNumber:: ISL6612ACBZ-T

Brand:: Elantec Semiconductor - Intersil | Pack: | D/C: 06+

Availability:: Supply Ability: 1300/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-10-12

From Other Seller

Part Number:ISL6612ACBZ-T
US $0.46 - 0.46
Quantity:

piece

Product Summary

The isl6612acbz-t is a high frequency MOSFET driver specifically designed to drive upper and lower power N-Channel MOSFETs in a synchronous rectified buck converter topology. The isl6612acbz-t drives the upper gate to 12V, while the lower gate can be independently driven over a range from 5V to 12V. Applications of the isl6612acbz-t include: Core Regulators for Intel and AMD Microprocessors, High Current DC-DC Converters and High Frequency and High Efficiency VRM and VRD.

Parametrics

isl6612acbz-t absolute maximum ratings: (1) Supply Voltage (VCC) : 15V; (2) Supply Voltage (PVCC) : VCC +0.3V; (3) BOOT Voltage (VBOOT-GND) : 36V; (4) Input Voltage (VPWM) : GND -0.3V to 7V; (5) PHAS: GND -0.3VDC to 15VDC; (6) ESD Rating Human Body Model: Class I JEDEC STD.

Features

isl6612acbz-t features: (1) Pin-to-pin Compatible with HIP6601 SOIC family; (2) Dual MOSFET Drives for Synchronous Rectified Bridge; (3) Advanced Adaptive Zero Shoot-Through Protection; (4) Advanced Adaptive Zero Shoot-Through Protection; (5) 36V Internal Bootstrap Schottky Diode; (6) Bootstrap Capacitor Overcharging Prevention; (7) Expandable Bottom Copper Pad for Enhanced Heat Sinking; (8) Three-State PWM Input for Output Stage Shutdown; (9) Dual Flat No-Lead (DFN) Package; (10) Pb-Free Plus Anneal Available (RoHS Compliant).
