IMP560ESA

IMP560ESA, 7.0V, 400mW, 200 nA, Electroluminescent (EL) lamp driver, SQP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.73~0.73 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 2985 :	0.73 / Piece

PartNumber:: IMP560ESA

Brand:: IMP, Inc - IMP | Pack: SQP | D/C: 99+

Availability:: Supply Ability: 100/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-08

From Other Seller

Part Number:IMP560ESA
US $0.73 - 0.73
Quantity:

piece

Product Summary

The imp560esa is an Electroluminescent (EL) lamp driver designed for systems with low EL lamp drive voltage requirements. The imp560esa is ideal for low ambient light applications or where small lamps are used. With just onehalf the inductor current of the IMP803, the imp560esa reduces system power consumption and extends battery life. Applications are (1)Night lights; (2)Automotive displays; (3)Cellular phones; (4)Pagers; (5)Clocks and radios; (6)Portable GPS receivers; (7)LCD module backlights.

Parametrics

imp560esa absolute maximum ratings: (1)Supply Voltage, VDD, VRSW-OSC and VREL-OSC: –0.5V to +7.0V; (2)Output Voltage, VCS: –0.5V to +120V; (3)Operating Temperature Range: –40°C to +85°C; (4)Storage Temperature Range: –65°C to +150°C; (5)Power Dissipation (SO): 400mW; (6)Power Dissipation (MicroSO): 300mW; (7)Quiescent VDD Supply Current, Disabled IDDIS VRSW-OSC <100mV: 50 to 200 nA.

Features

imp560esa features: (1)112V peak-to-peak typical AC output voltage; (2)Low input current (w/inductor current): 12mA; (3)Low disabled input current: 50nA; (4)Wide operating voltage range - from 2.0V to 6.5V; (5)Simple design requires few passive components; (6)Adjustable output lamp frequency controls lamp color and power consumption; (7)Adjustable converter frequency for minimum power consumption; (8)IMP803 pin-compatible; (9)MicroSO package option.
