HCF4094BEY

8-stage serial shift register, 20V, 200mW, 10 mA, DIP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.16~0.16 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 200 :	0.16 / Piece

PartNumber:: HCF4094BEY

Brand:: STMicroelectronics - ST | Pack: DIP | D/C: 02+

Availability:: Supply Ability: 100/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-01

From Other Seller

Part Number:HCF4094BEY
US $0.16 - 0.16
Quantity:

piece

Product Summary

The hcf4094bey is a monolithic integrated circuit available in 16-lead dual in-line plastic or ceramic packageand plastic micropackage. The hcf4094bey is an 8-stage serial shift register having a storage latch associated with each stage for strobing data from the serial input to parallel buffered 3-state outputs.

Parametrics

hcf4094bey absolute maximum ratings: (1)VDD Supply Voltage :HCC Types: -0.5 to + 20V, HCF Types: -0.5 to + 18V; (2)Vi Input Voltage: -0.5 to VDD + 0.5 V; (3)II DC Input Current (any one input): ± 10 mA; (4)Pto t Total Power Dissipation (per package)Dissipation per Output Transistor for Top = Full Package-temperature Range 200mW, 100 mW; (5)Top Operating Temperature : HCC Types: -55 to + 125°C, HCF Types -40 to + 85 °C; (6)Tstg Storage Temperature: -65 to + 150 °C.

Features

hcf4094bey features: (1)3-state parallel outputs for con-nectionto common bus; (2)separate serial outputs synchronousto both positive and nega tive clock edges for cascading medium speedoperation 5mhz at 10v standardized symmetrical output characteristics; (3)quiescent current specified to 20v for hcc device; (4)5v, 10v, and 15v parametric ratings input currentof 100na at 18v and 25°c for hcc device; (5)100% testedfor quiescent current; (6)meets all requirementsofjedectentative standard n°. 13A, ”standard specifications for description of ”b” seriescmos devices”.
