AT25020N-10SI-2.7

AT25020N-10SI-2.7, SPI Serial EEPROM, 7.0V, 5.0 mA, 20 MHz, dip

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.21~0.21 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 4000 :	0.21 / Piece

PartNumber:: AT25020N-10SI-2.7

Brand:: ACCUTEK MICROCIRCUIT CORPORATION - Accutek | Pack: | D/C: 03+

Availability:: Supply Ability: 4000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-08-22

From Other Seller

Part Number:AT25020N-10SI-2.7
US $0.21 - 0.21
Quantity:

piece

Product Summary

The at25020n-10si-2.7 is a SPI Serial EEPROM. The at25020n-10si-2.7 provides 2048 bits of serial electrically erasable programmable read-only memory (EEPROM) organized as 256 words of 8 bits each. The at25020n-10si-2.7 is optimized for use in many industrial and commercial applications where low-power and low-voltage operation are essential. The at25020n-10si-2.7 is available in space saving 8-lead PDIP, 8-lead JEDEC SOIC, 8-lead Ultra Thin mini-MAP (MLP 2x3), and 8-lead TSSOP packages.

Parametrics

at25020n-10si-2.7 absolute maximum ratings: (1)Operating Temperature:-40℃ to + 125℃; (2)Storage Temperature:-65℃ to + 150℃; (3)Voltage on Any Pin with Respect to Ground:-1.0V to + 7.0V; (4)Maximum Operating Voltage:6.25V; (5)DC Output Current: 5.0 mA.

Features

at25020n-10si-2.7 features: (1)Serial Peripheral Interface (SPI) Compatible; (2)Supports SPI Modes 0 (0,0) and 3 (1,1):Data Sheet Describes Mode 0 Operation; (3)Low-voltage and Standard-voltage Operation:2.7 (VCC = 2.7V to 5.5V), 1.8 (VCC = 1.8V to 5.5V); (4)20 MHz Clock Rate (5V) ; (5)8-byte Page Mode; (6)Block Write Protection:Protect 1/4, 1/2, or Entire Array; (7)Write Protect (WP) Pin and Write Disable Instructions for Both Hardware and Software Data Protection; (8)Self-timed Write Cycle (5 ms max); (9)High Reliability: Endurance: One Million Write Cycles, Data Retention: 100 Years; (10)Automotive Devices Available; (11)8-lead JEDEC PDIP, 8-lead JEDEC SOIC, 8-lead Ultra Thin mini-MAP (MLP 2x3) and 8-lead TSSOP Packages ; (12)Die Sales: Wafer Form, Waffle Pack, Bumped Wafers.
