Product Summary
The apl1117vc-trg is a low dropout three-terminal adjustable regulator with 1A output current capability. In order to obtain lower dropout voltage and faster transient response, which is critical for low voltage applications , the apl1117vc-trg has been optimized. The apl1117-33vc-tr is available in the industry standard 3-pin TO-220, TO-252, TO- 263, and the low profile surface mount SOT-223 power packages which can be used in applications where space is limited. Applications are (1)Active SCSI Terminators; (2)Low Voltage Logic Supplies; (3)Battery-Powered Circuitry; (4)Post Regulator for Switching Power Supply.
Parametrics
apl1117vc-trg absolute maximum ratings: (1)Storage temparature TSTG: –65 ~ +150 °C; (2)Operating temparature TOPR: –40 ~ +85 °C; (3)Supply Voltage VCC max.: 7 V; (4)Power dissipation Pd: 1.0 W; (5)Input impedance ZINbias at Bias select: 100 to 200 kΩ; (6)Voltage gain Gn *3 SIN wave:1V f=100kHz: 5.7 to 6.3 dB.
Features
apl1117vc-trg features: (1)Guaranteed Output Voltage Accuracy within 2%; (2)Fast Transient Response; (3)Guaranteed Dropout Voltage at Multiple Currents; (4)Load Regulation : 0.1% Typ.; (5)Line Regulation : 0.03% Typ.; (6)Low Dropout Voltage : 1.1V Typ. at IOUT =1A; (7)Current Limit : 1A Typ. at TJ=25°C; (8)On-Chip Thermal Limiting : 150°C Typ.; (9)Adjustable Output : 1.25~10.7V; (10)Standard 3-pin TO-220, TO-252, TO-263 and SOT-223 Power Packages.
Diagrams
