Product Summary
The amd-k6-2+/550acz processor with 3DNow technology is a functionally compatible embedded version of the sixth generation, Microsoft Windows compatible AMD-K6-2 processor. The amd-k6-2+/550acz embedded processor delivers the same high performance and incorporates the same leading-edge features, including the innovative and efficient RISC86 microarchitecture, a large 64-Kbyte level-one cache (32-Kbyte dual-ported data cache, 32-Kbyte instruction cache with predecode data), and a powerful IEEE 754-compatible and 854-compatible floating-point execution unit.
Parametrics
amd-k6-2+/550acz absolute maximum ratings: (1)VCC2: 2.4 V; (2)VCC3: 3.6 V; (3)VPIN: –0.5 V to VCC3 + 0.5 V and < 4.0 V; (4)TCASE (under bias): –65°C to +110°C; (5)TSTORAGE: –65°C to +150°C.
Features
amd-k6-2+/550acz features: (1)Teparallel specialized executiounits; (2)Multiple sophisticated x86-to-RISC86 instructiodecoders; (3)Advanced two-level branch prediction; (4)321-piceramic pigrid array (CPGA)package; (5)Socket 7 platform compatible, 66-MHz frontside bus; (6)Super7 platform compatible, 100-MHz frontside bus supported othe 300-MHz, 350-MHz, and 400-MHz versions of the AMD-K6-2E processor; (7)High-performance industry-standard MMX instructions; (8)Dual integer ALU for superscalar execution; (9)High-performance IEEE 754-compatible and 854-compatible floating-point unit; (10)Industry-standard system management mode (SMM); (11)IEEE 1149.1 boundary scan; (12)x86 binary software compatibility; (13)Low-power 0.25-microprocess technology.
Diagrams
