TPS2830DR

TPS2830DR, MOSFET driver, 16 V, 100-ns, 2.4-A, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~1.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10000 :	1.00 / Piece

PartNumber:: TPS2830DR

Brand:: Texas Instruments - TI | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 4/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-13

From Other Seller

Part Number:TPS2830DR
US $1.00 - 1.00
Quantity:

piece

Product Summary

The TPS2830DR is a MOSFET driver for synchronous-buck power stages. The TPS2830DR is ideal for designing a high-performance power supply using a switching controller that does not include suitable MOSFET drivers on the chip. The TPS2830DR is designed to deliver 2.4-A peak currents into large capacitive loads. Higher currents can be controlled by using multiple drivers in a multiphase configuration. The high-side driver can be configured as a ground-reference driver or as a floating bootstrap driver. An adaptive dead-time control circuit eliminates shoot-through currents through the main power FETs during switching transitions, and provides high efficiency for the buck regulator.

Parametrics

TPS2830DR absolute maximum ratings: (1)Supply voltage range, VCC: –0.3 V to 16 V; (2)Input voltage range: BOOT to PGND (high-side driver ON): –0.3 V to 30 V BOOTLO to PGND: –0.3 V to 16 V, BOOT to BOOTLO: –0.3 V to 16 V, ENABLE, SYNC, and CROWBAR: –0.3 V to 16 V, IN: –0.3 V to 16 V, DT: –0.3 V to 30 V; (3)Operating virtual junction temperature range, TJ: –40°C to 125°C; (4)Storage temperature range, Tstg: –65°C to 150°C; (5)Lead temperature soldering 1,6 mm (1/16 inch)from case for 10 seconds: 260°C.

Features

TPS2830DR features: (1)Floating Bootstrap or Ground-Reference High-Side Driver; (2)Active Deadtime Control; (3)50-ns Max Rise/Fall Times and 100-ns Max Propagation Delay — 3-nF Load; (4)Ideal for High-Current Single or Mutiphase Applications; (5)2.4-A Typ Peak Output Current; (6)4.5-V to 15-V Supply Voltage Range; (7)Internal Schottky Bootstrap Diode; (8)SYNC Control for Synchronous or Nonsynchronous Operation; (9)CROWBAR for OVP, Protects Against Faulted High-Side Power FETs; (10)Low Supply Current. 3-mA Typ –40°C to 125°C Junction-Temperature Operating Range.
