TC74VHC245F

TC74VHC245F, CMOS OCTAL BUS TRANSCEIVER, 7.0 V, 75 mA, 180 mW, sop

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.30 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1366 :	0.30 / Piece

PartNumber:: TC74VHC245F

Brand:: Toshiba Semiconductor - Toshiba | Pack: | D/C: 03+

Availability:: Supply Ability: 3/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-21

From Other Seller

Part Number:TC74VHC245F
US $0.30 - 0.30
Quantity:

piece

Product Summary

The TC74VHC245F is an advanced high speed CMOS OCTAL BUS TRANSCEIVER fabricated with silicon gate C2MOS technology. The TC74VHC245F achieves the high speed operation similar to equivalent Bipolar Schottky TTL while maintaining the CMOS low power dissipation. The TC74VHC245F is intended for two-way asynchronous communication between data busses. The direction of data transmission is determined by the level of the DIR input. The enable input (G ) can be used to disable the device so that the busses are effectively isolated.

Parametrics

TC74VHC245F absolute maximum ratings: (1)Supply voltage range VCC: -0.5 to 7.0 V; (2)DC input voltage (DIR, G)VIN: -0.5 to 7.0 V; (3)DC bus I/O voltage VI/O: -0.5 to VCC + 0.5 V; (4)Input diode current IIK: -20 mA; (5)Output diode current IOK: ±20 mA; (6)DC output current IOUT: ±25 mA; (7)DC VCC/ground current ICC: ±75 mA; (8)Power dissipation PD 180 mW; (9)Storage temperature Tstg: -65 to 150 °C.

Features

TC74VHC245F features: (1)High speed: tpd = 4.0 ns (typ.)at VCC = 5 V; (2)Low power dissipation: ICC = 4 μA (max)at Ta = 25°C; (3)High noise immunity: VNIH = VNIL = 28% VCC (min); (4)Balanced propagation delays: tpLH −∼ tpHL; (5)Wide operating voltage range: VCC (opr)= 2 V to 5.5 V; (6)Low noise: VOLP = 1.2 V (max); (7)Pin and function compatible with 74ALS245.
