ST890CDR

ST890CDR, P-Channel MOSFET power switch, 6 V, 1.5 A, 90mW, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~1.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100000 :	1.00 / Piece

PartNumber:: ST890CDR

Brand:: STMicroelectronics - ST | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 4/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-07

From Other Seller

Part Number:ST890CDR
US $1.00 - 1.00
Quantity:

piece

Product Summary

The ST890CDR is a low voltage, P-Channel MOSFET power switch intended for high side load switching applications. Internal current limiting circuitry protects the input supply against overload. Thermal overload protection limits power dissipation and junction temperatures. The ST890CDR maxmimum current limits is 1.2A. The current limit through the switch is programed with a resistor from SET to groung. The ST890CDR is available in SO-8 package. Main applications are: PCMCIA slots, Access bus slots, Portable equipment.

Parametrics

ST890CDR absolute maximum ratings: (1)VI Supply Voltage: -0.5 to 6 V; (2)VON, VFAULT Power DMOS Drain to Source Voltage: -0.5 to 6 V; (3)VSET, VO Logic Input Voltage: -0.5 to (VIN + 0.5)V; (4)IDS Maximum Continuous Switching Current : 1.5 A; (5)Tstg Storage Temperature Range: -65 to +150 °C; (6)Top Operating Junction Temperature Range (C series)0 to +70°C, (B series)-40 to +85°C.

Features

ST890CDR features: (1)2.7V TO 5.5V input range; (2)programmable current limit up to 1.2A; (3)low quiescent current; (4)thermal shutdown; (5)fault indicator output; (6)90mW (TYP.)oresistance; (7)SO-8 package.
