Product Summary

The SN75LVDS32DR is a differential line receiver that implement the electrical characteristics of low-voltage differential signaling (LVDS). The SN75LVDS32DR signaling technique lowers the output voltage levels of 5-V differential standard levels (such as EIA/TIA-422B) to reduce the power, increase the switching speeds, and allow operation with a 3.3-V supply rail. Any of the four differential receivers provides a valid logical output state with a ±100 mV allow operation with a differential input voltage within the input common-mode voltage range. The input common-mode voltage range allows 1 V of ground potential difference between two LVDS nodes.

Parametrics

SN75LVDS32DR absolute maximum ratings: (1)Supply voltage range, VCC (see Note 1): –0.5 V to 4 V; (2)Input voltage range, VI –0.5 V to VCC + 0.5 V; (3)Input voltage range, VI: (A or B). –0.5 V to 4 V; (4)Continuous total power dissipation: see dissipation rating table; (5)Storage temperature range, Tst: –65􀀀C to 150 ℃; (6)Lead temperature 1,6 mm (1/16 inch)from case for 10 seconds: 260 ℃.

Features

SN75LVDS32DR features: (1)Meets or exceeds the requirements of ansi tia/eia-644 standard; (2)Operates with a single 3.3-v supply; (3)Designed for signaling rate of up to 155 mbps; (4)Differential input thresholds ±100 mv max; (5)Low-Voltage TTL (LVTTL)logic output levels; (6)Open-circuit fail safe; (7)Characterized for operation from 0°c to 70°c.
