Product Summary

The MIC2561-1BM VCC & VPP is a Matrix controls PCMCIA memory card power supply pins, both VCC and VPP. The MIC2561-1BM switches voltages from the system power supply to VCC and VPP. The MIC2561-1BM switches between the three VCC voltages (OFF, 3.3V and 5.0V) and the VPP voltages (OFF, 0V, 3.3V, 5V, or 12.0V) required by PCMCIA cards. Applications are (1)PCMCIA Power Supply Pin Voltage Switch; (2)Data Collection Systems; (3)Machine Control Data Input Systems; (4)Wireless Communications; (5)Bar Code Data Collection Systems; (6)Instrumentation Configuration/Datalogging; (7)Docking Stations (portable and desktop); (8)Power Supply Management; (9)Power Analog Switching.

Parametrics

MIC2561-1BM absolute maximum ratings: (1)Power Dissipation, TAMBIENT ≤ 25°C: Internally Limited; (2)Power Dissipation SOIC: 800 mW; (3)Derating Factors (To Ambient)SOIC: 4 mW/°C; (4)Storage Temperature: –65°C to +150°C; (5)Maximum Operating Temperature (Die): 125°C; (6)Operating Temperature (Ambient): 0°C to +70°C; (7)Lead Temperature (5 sec): 260°C; (8)Supply Voltage, VPP IN: 15V; (9)VCC3 IN: VCC5 IN; (10)VCC5 IN: 7.5V; (11)Logic Input Voltages: –0.3V to +15V; (12)Output Current (each Output)VPP OUT: Internally Limited; (13)Output Current (each Output)VCC OUT: Internally Limited; (14)Output Current (each Output)VCC OUT, Suspend Mode: 600mA.

Features

MIC2561-1BM features: (1)Complete PCMCIA VCC and VPP Switch Matrix in a Single IC; (2)No External Components Required; (3)Controlled Switching Times; (4)Logic Options for Compatible with Industry Standard PCMCIA Controllers; (5)No Voltage Overshoot or Switching Transients; (6)Break-Before-Make Switching; (7)Output Current Limit and Over-Temperature Shutdown; (8)Digital Flag for Error Condition Indication; (9)Ultra Low Power Consumption; (10)Digital Selection of VCC and VPP Voltages; (11)Over 750mA of VCC Output Current; (12)200mA of VPP Output Current; (13)14-Pin SOIC Package.
