MAX1774

MAX1774, dual, high-efficiency, step-down converter, 30 V, 1.25 MHz, 8 μA, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.80~1.80 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	1.80 / Piece

PartNumber:: MAX1774

Brand:: Maxim Integrated Products - Maxim | Pack: SOP | D/C: 07+

Availability:: Supply Ability: 4/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-18

From Other Seller

Part Number:MAX1774
US $1.80 - 1.80
Quantity:

piece

Product Summary

The MAX1774 is a complete power-supply solution for PDAs and other hand-held devices. The MAX1774 integrates two high-efficiency step-down converters, a boost converter for backup battery regulation, and four voltage detectors in a small 32-pin QFN or 28-pin QSOP package. Applications are (1)Hand-Held Computers; (2)PDAs; (3)Internet Access Tablets; (4)POS Terminals; (5)Subnotebooks.

Parametrics

MAX1774 absolute maximum ratings: (1)IN, SHDNM, MDRV, DBI, LBI, ACI, CVH to GND: -0.3V to +30V; (2)IN to CVH, PDRV: -0.3V to +6V; (3)BIN to CS-: -0.3V to +6V; (4)LXB to GND: -0.3V to (VBIN+ 0.7V); (5)PDRV to GND: (VCVH - 0.3V)to (VIN + 0.3V); (6)All Other Pins to GND: -0.3V to +6V; (7)PGND to GND : -0.3V to +0.3V; (8)Continuous Power Dissipation 28-Pin QSOP (derate 10.8mW/°C above +70°C): 860mW; (9)32-Pin QFN (derate 23.2mW/°C above +70°C): 1860mW; (10)Operating Temperature: -40°C to +85°C; (11)Storage Temperature: -65°C to +150°C; (12)Temperature (soldering, 10s): +300°C.
