M74HC125RM13TR

M74HC125RM13TR, quad bus buffer, 7 V, 35 mA, 500 mW, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.30 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 3000 :	0.30 / Piece

PartNumber:: M74HC125RM13TR

Brand:: STMicroelectronics - ST | Pack: SOP | D/C: 10+

Availability:: Supply Ability: 4/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-19

From Other Seller

Part Number:M74HC125RM13TR
US $0.30 - 0.30
Quantity:

piece

Product Summary

The M74HC125RM13TR is a quad bus buffer. The M74HC125RM13TR requires the 3-STATE control input G to be set high to place the output into the high impedance state.

Parametrics

M74HC125RM13TR absolute maximum ratings: (1)VCC Supply Voltage: -0.5 to +7 V; (2)VI DC Input Voltage: -0.5 to VCC + 0.5 V; (3)VO DC Output Voltage: -0.5 to VCC + 0.5 V; (4)I IK DC Input Diode Current : ± 20 mA; (5)IOK DC Output Diode Current: ± 20 mA; (6)IO DC Output Current : ± 35 mA; (7)ICC or IGND DC VCC or Ground Current: ± 70 mA; (8)PD Power Dissipation : 500(*)mW; (9)Tstg Storage Temperature: -65°C to +150 °C; (10)TL Lead Temperature: (10 sec)300 °C.

Features

M74HC125RM13TR features: (1)high speed: tPD = 8s (TYP.)at VCC = 6V; (2)low power dissipation: ICC = 4µA(MAX.)at TA=25°C; (3)high noise immunity: VNIH = VNIL = 28 % VCC (MIN.); (4)symmetrical output impedance: |IOH| = IOL = 6mA (MIN); (5)balanced propagation delays: tPLH - tPHL; (6)wide operating voltage range: VCC (OPR)= 2V to 6V; (7)pin and function compatible with 74 series 125.
