LMX3161VBHX

single Chip Radio Transceiver, 5.5V, 6.5 dB, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $3.00~3.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10000 :	3.00 / Piece

PartNumber:: LMX3161VBHX

Brand:: National Semiconductor - NS | Pack: SOP | D/C: 05+

Availability:: Supply Ability: 4/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-21

From Other Seller

Part Number:LMX3161VBHX
US $3.00 - 3.00
Quantity:

piece

Product Summary

The LMX3161VBHX is a single Chip Radio Transceiver which is a monolithic,integrated radio transceiver optimized for use in a Digital Enhanced Cordless Telecommunications (DECT) system. Applications include Digital Enhanced Cordless Telecommunications (DECT), Personal wireless communications (PCS/PCN), Wireless local area networks (WLANs) and Other wireless communications systems.

Parametrics

LMX3161VBHX absolute maximum rating: (1)Power Supply Voltage: -0.3V to +6.5V; (2)Voltage on Any Pin：-0.3V to VCC +0.3V; (3)Storage Temperature Range: -65℃ to +150℃; (4)Lead Temp. (solder, 4 sec): +260℃.

Features

LMX3161VBHX features: (1)Single chip solution for DECT RF transceiver; (2)RF sensitivity to -93 dBm; RSSI sensitivity to -100 dBm; (3)Two regulated voltage outputs for discrete amplifiers; (4)High gain (85 dB) intermediate frequency strip; (5)Allows unregulated 3.0V–5.5V supply voltage; (6)Power down mode for increased current savings; (7)System noise figure 6.5 dB (typ).
