Product Summary
The HT46F47E Cost-Effective A/D Flash Type MCU with EEPROM Devices is a series of 8-bit high performance RISC architecture microcontroller, designed especially for applications that interface directly to analog signals, such as those from sensors. The HT46F47E includes an integrated multi-channel Analog to Digital Converter in addition to one or two Pulse Width Modulation outputs.
Parametrics
HT46F47E absolute maximum ratings: (1)Supply Voltage : VSS-0.3V to VSS+6.0V; (2)Storage Temperature : -50°C to 125°C; (3)Input Voltage: VSS-0.3V to VDD+0.3V Operating Temperature: -40°C to 85°C; (4)IOL Total : 150mA IOH Total: 100mA; (5)Total Power Dissipation : 500mW.
Features
HT46F47E features: (1)13 to 23 bidirectional I/O lines; (2)External interrupt input shared with an I/O line; (3)8-bit programmable Timer/Event Counter with overflow interrupt and 7-stage prescaler; (4)On-chip crystal and RC oscillator; (5)Watchdog Timer function; (6)PFD for audio frequency generation; (7)Power down and wake-up functions to reduce power consumption; (8)Up to 0.5μs instruction cycle with 8MHz system clock at VDD=5V; (9)4 or 6-level subroutine nesting; (10)4 channels 8 or 9-bit resolution A/D converter; (11)1 or 2 channel 8-bitPWMoutput shared with I/O lines; (12)Bit manipulation instruction; (13)Table read instructions; (14)63 powerful instructions; (15)All instructions executed in one or two machine cycles.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 HT46F47E |
Other |
|
Data Sheet |
Negotiable |
|
||||
