Product Summary
The 920-ST03 is high performance module for single fiber communications by using 1490 nm transmitter and 1310 nm receiver. The 920-ST03 section uses a multiple quantum well DFB laser and is a class 1 laser compliant according to International Safety Standard IEC-60825. The receiver section uses an integrated 1310 nm detector preamplifier (IDP) mounted in an optical header and a limiting post-amplifier IC. A LVPECL logic interface simplifies interface to external circuitry.
Parametrics
920-ST03 absolute maximum ratings: (1)Storage Temperature Tstg: -40 to 85 ℃; (2)Operating Temperature Topr: 0 to 70 ℃; (3)Soldering Temperature: 260 ℃; (4)Power Supply Voltage Vcc:0 to 4.5 V; (5)Input Voltage: GND to Vcc V; (6)Output Current Iout: 0 to 30 mA.
Features
920-ST03 features: (1)Single Fiber Bi-DirectionaTransceiver; (2)1490 nm DFB LD Transmitter; (3)1310 nm Receiver; (4)Industry Standard 1 x 9 Footprint; (5)Single +3.3 V Power Supply; (6)RoHS Compliant; (7)LVPECL DifferentiaInputs and Outputs; (8)0 to 70oC Operating : BTR-5920G; (9)-20 to 85oC Operating : BTR-5920AG; (10)Wave Solderable and AqueousWashable; (11)Class 1 Laser InternationaSafety Standard IEC-60825 Compliant.
Diagrams
