74V1T08STR

single 2-input AND gate, 7V, ±25mA, SOT

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.06~0.06 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 3000 :	0.06 / Piece

PartNumber:: 74V1T08STR

Brand:: STMicroelectronics - ST | Pack: BGA | D/C: 05+

Availability:: Supply Ability: 3000/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-15

From Other Seller

Part Number:74V1T08STR
US $0.06 - 0.06
Quantity:

piece

Product Summary

The 74v1t08str is an advanced high-speed CMOS single 2-input AND gate fabricated with sub-micron silicon gate and double-layer metal wiring C2MOS technology. The internal circuit of the 74v1t08str is composed of 2 stages including buffer output, which provide high noise immunity and stable output. The 74v1t08str can be used to interface 5V to 3V.

Parametrics

74v1t08str absolute maximum ratings: (1) Supply Voltage Vcc: -0.5 to +7V; (2) DC Input Voltage VI: -0.5 to +7V; (3) DC Output Voltage VO: -0.5 to VCC +0.5V; (4) DC Input Diode Current IIK: -20mA; (5) DC Output Diode Current IOK: ±20mA; (6) DC Output Current IO: ±25mA; (7) DC VCC or Ground Current ICC or IGND: ±50mA; (8) Storage Temperature Tstg: -65 to +150°C; (9) Lead Temperature (10sec) TL: 300°C.

Features

74v1t08str features: (1) high speed: tPD=4.7ns (TYP.) at Vcc=5V; (2) low power dissipation: Icc=1μA (Max.) at TA=25°C; (3) compatible with outputs; (4) power down protection on inputs; (5) symmetrical output impedance; (6) balanced propagation delays: tPLH=tPHL; (7) operating voltage range: Vcc (OPR) =4.5 to 5.5V; (8) IMMPPROVED latch-up immunity.
