2SA1020-Y

2sa1020-y, Silicon PNP Epitaxial Type Transistor, -50V, -2A, TO-92MOD

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.09~0.09 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 30000 :	0.09 / Piece

PartNumber:: 2SA1020-Y

Brand:: Toshiba Semiconductor - Toshiba | D/C: 10+

Availability:: Supply Ability: 30000/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-25

From Other Seller

Part Number:2SA1020-Y
US $0.09 - 0.09
Quantity:

piece

Product Summary

The 2sa1020-y is a kind of Silicon PNP Epitaxial Type Transistor for Power Amplifier and Power Switching Applications.

Parametrics

2sa1020-y absolute maximum ratings: (1)Collector-to-Base Voltage, VCBO: -50 V; (2)Collector-to-Emitter Voltage, VCEO: -50 V; (3)Emitter-to-Base Voltage, VEBO: -5 V; (4)Collector Current, IC: -2 A; (5)Base current, IB: 0.2 A; (6)Collector Dissipation, PC: 900 mW; (7)Junction Temperature, Tj: 150℃; (8)Storage Temperature, Tstg: -55 to +150℃.

Features

2sa1020-y features: (1)Low Collector saturation voltage: VCE (sat) = .0.5 V (max) (IC = .1 A); (2)High collector power dissipation: PC = 900 mW; (3)High-speed switching: tstg = 1.0 us (typ.); (4)Complementary to 2SC2655.
