MBR0540T1G

MBR0540T1G, schottky power rectifier, 40 V, 0.5 A, 20 kHz, MBR

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.02~0.02 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 2400 :	0.02 / Piece

PartNumber:: MBR0540T1G

Brand:: ON Semiconductor - ON | Pack: | D/C: 05+

Availability:: Supply Ability: 100/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-11

From Other Seller

Part Number:MBR0540T1G
US $0.02 - 0.02
Quantity:

piece

Product Summary

The MBR0540T1G is a schottky power rectifier. It employs the schottky barrier principle with a barrier metal that produces optimal forward voltage drop-reverse current tradeoff. Ideally suited for low voltage, high frequency rectification, or as a free wheeling and polarity protection diodes in surface mount applications where compact size and weight are critical to the system. This package provides an alternative to the leadless 34 MELF style package.

Parametrics

MBR0540T1G absolute maximum ratings: (1)Peak Repetitive Reverse Voltage Working Peak Reverse Voltage DC Blocking Voltage: 40 V; (2)Average Rectified Forward Current (At Rated VR, TC = 115°C): 0.5 A; (3)Peak Repetitive Forward Current (At Rated VR, Square Wave, 20 kHz, TC = 115°C): 1.0 A; (4)Non-Repetitive Peak Surge Current (Surge Applied at Rated Load Conditions Halfwave, Single Phase, 60 Hz: 5.5 A; (5)Storage/Operating Case Temperature Range: -55 to +150 °C; (6)Operating Junction Temperature: -55 to +150 °C; (7)Voltage Rate of Change (Rated VR, TJ = 25°C): 1000 V/μs.

Features

MBR0540T1G features: (1)Guardring for Stress Protection; (2)Very Low Forward Voltage; (3)Epoxy Meets UL 94 V-0 @ 0.125 in; (4)Package Designed for Optimal Automated Board Assembly; (5)Pb-Free Packages are Available.
