LF351N

LF351N, JFET input operational amplifier, 670 mW, 18V, 50 pA, DIP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.22~0.22 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.22 / Piece

PartNumber:: LF351N

Brand:: STMicroelectronics - ST | Pack: | D/C: 06+

Availability:: Supply Ability: 1000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-08-22

From Other Seller

Part Number:LF351N
US $0.22 - 0.22
Quantity:

piece

Product Summary

The LF351N is a low cost high speed JFET input operational amplifier with an internally trimmed input offset voltage (BI-FET IITM technology). The device requires a low supply current and yet maintains a large gain bandwidth product and a fast slew rate. In addition, well matched high voltage JFET input devices provide very low input bias and offset currents. The LF351N is pin compatible with the standard LM741 and uses the same offset voltage adjustment circuitry. This feature of LF351N allows designers to immediately upgrade the overall performance of existing LM741 designs.

Parametrics

LF351N absolute maximum ratings: (1)Supply Voltage: 18V; (2)Power Dissipation: 670 mW; (3)Operating Temperature Range: 0℃ to +70℃; (4)Tj(MAX): 115℃; (5)Differential Input Voltage: ±30V; (6)Input Voltage Range: ±15V; (7)Output Short Circuit Duration: Continuous; (8)Storage Temperature Range: -65℃ to +150℃; (9)Lead Temp. (Soldering, 10 sec.): Metal Can: 300℃, DIP: 260℃.

Features

LF351N features: (1)Internally trimmed offset voltage: 10 mV; (2)Low input bias current: 50 pA; (3)Low input noise voltage: 25 nV/√Hz; (4)Low input noise current: 0.01 pA/√Hz; (5)Wide gain bandwidth: 4 MHz; (6)High slew rate: 13 V/μs; (7)Low supply current: 1.8 mA; (8)High input impedance: 1012Ω; (9)Low total harmonic distortion AV=10, RL=10k, VO=20 Vp-p, BW=20 Hz±20 kHz: <0.02% ; (10)Low 1/f noise corner: 50 Hz; (11)Fast settling time to 0.01%: 2 μs.
